Sistemul contine:
8x Cameră de supraveghere pentru exterior analogică, 5MP, lentilă 2.8mm, IR20m, IP67 – UNV UAC-B115-F28
1x XVR Hibrid, 8 canale AnalogHD 5MP lite + 4 canale IP 4MP, Audio over coaxial, H.265 – UNV XVR301-08G3
1x Splitter distribuitor alimentare 8 camere
1x Alimentator YDS sursa 7A 12V in comutatie cu fir
8x Cablu sertizat 10m BNC+DC, alimentare si semnal video
1x Hard disk 500GB
DESCRIERE PRODUSE:
Cameră de supraveghere- UAC-B115-F28
UAC-B115-F28 este o camera analog Mini Bullet de la Uniview cu urmatoarele caracteristici:
- Rezolutie 5MP;
- Semnal video TVI/AHD/CVI/CVBS;
- Smart IR pana la 20 metri;
- WDR digital;
- Clasa protectie IP67.
Specificatii
| Model / producator | UNV (Uniview) |
| Senzor | 1/2.7″ 5.0MP high quality image |
| Rezolutie | 5MP (2880×1620)@30fps, 4MP/1080P |
| Lentila | 2.8mm, unghi vizualizare 102.2° |
| Iluminare minima | 0.02 Lux (F2.0, AGC ON) , 0 Lux cu IR |
| Distanta IR | 20 metri, IR-CUT filter cu AUTO-switch |
| Alimentare | 12 V DC ± 25% |
| Consum | max. 5.04W |
| Temperatura de operare | -30°C ~ +60°C, IP67 |
| Dimensiuni | 142mm × 63mm × 65mm |
| Greutate | 135 gr. |
| WDR | DWDR |
| Protectie la descarcari electrice | 4KV |
| Semanl video | TVI/AHD/CVI/CVBS |
Documente si manuale
| Specificatii tehnice UAC-B115-F28 | |
| Certificat conformitate EMC | |
| Certificat conformitate LVD |
XVR Hibrid- UNV XVR301-08G3
Descriere
XVR Hibrid de la Uniview, suporta camere analog HD si IP cu rezolutie de pana la 5MP lite, capacitate 8 canale Analog + 4 canale IP (sau pana la 8 canale IP, exclus analog): TVI/AHD/CVI/CVBS/IP, playback sincron pe 4 canale HD sau 8 canale SD la o rezolutie maxima de 2MP, capacitate stocare 1 HDD maxim 8TB (neinclus). Suporta Audio over Coaxial pentru camere TVI. Accepta camere ce au protocol ONVIF si RTSP. Suporta detectia miscarii.
Specificatii
| Model / producator | UNV (Uniview) |
| Inregistrare | 5MPLite@6fps, 4MPLite@8fps, 1080Lite@12fps, 720P@12fps |
| Camere suportate | HDTVI/AHD/CVI, CVBS +4 ch. IP max 4MP |
| Compresie | H.265, H.264 |
| Redare | 1-4 HD / 1-8 SD canale sincronizate |
| Intrari | 8 x BNC; 1 x audio, LAN 10/100, 2xUSB |
| Iesiri | HDMI, VGA, 1 audio |
| Stocare | 1 x HDD SATA max. 8TB (neinclus) |
| Stream | 5MP Lite/4MP Lite /1080P/1080P Lite/720P/CIF |
| Alimentare | 12V DC |
| Consum | max. 8W (fara HDD) |
| Dimensiuni | 260 × 226 × 47 mm |
| Alarma IN/OUT | Nu are |
| Audio | 8 x audio over coaxial TVI, 1 x analogic RCA |
| Greutate | max. 1.1 Kg (fara HDD) |
| Temperatura operare | -10°C ~+55°C |
| Latime banda | intrare 32Mbs / iesire 64Mbs |
Documente si manuale
| Specificatii tehnice XVR301-08G4 | |
| Certificat conformitate EMC | |
| Certificat conformitate LVD |
Cablu sertizat 10 metri pentru camere de supraveghere
Cablu mufat si serizat pentru conectarea camerelor de supraveghere la DVR.
Se recomanda folosirea cablului sertizat pentru conectarea camerelor de supraveghere digitale (AHD/TVI/CVI) cat si a celor analogice(CVBS).
La capete este echipat cu conectori turnati tip “BNC mama” (2) si conectori de alimentare tip DC tata (1) si DC mama (1)
Cablu sertizat 10 metri pentru camere de supraveghere cu conectori.
- BNC+DC
- alimentare +semnal video
- 2 DC Joint (Female and Male): 5.5*2.1mm
- pentru camere supraveghere
- grosime 4mm cupru
Vezi alte cabluri sertizate aici
Alimentator YDS sursa 7A 12V in comutatie cu fir
Sursa de alimentare in comutatie 7A / 12V model profesional pentru camere supraveghere.
- Tensiune de intrare: 90-240AC, 50-60Hz Tensiune de iesire: 7A
- Lungime cablu 100CM cablu alimentare la 220V de 50CM
- Protectie la suprasarcina, supratensiune, scurt-circuit, model laptop
- Cablul de iesire are mufa standard 5, 5mm x 2, 1 mm certificat CE, CCC, ROHS, FCC
- Input: AC90V-240V 50-60Hz – Input Current: 1.0A – Inrush Current: CCA 3A/240V – Leak Current
