Sistemul conține:
2x Cameră supraveghere IP, 4 MP, lentilă 2.8mm, IR 30m
1x NVR cu 4 canale IP, Ultra HD rezolutie 4K
1x HDD Toshiba 1 TB
1x Cablu CAT6 FTP rolă 100m
4x Conector RJ45 CAT6e – UTP
Detalii:
Cameră de supraveghere IP 4.0 MP, lentilă 2.8mm, IR 30m – HIKVISION
Descriere
Camera de supraveghere video IP Hikvision, rezolutie 4MP (2560×1440)@20fps, compresie H.265+/H.265/H.264, lentila 2.8mm, unghi vizualizare 98°, distanta IR max. 30m, IP67
Specificatii
Model / producator | HIKVISION |
Senzor | 1/3″ Progressive Scan CMOS |
Rezolutie | 4MP (2560 × 1440)/1080P (1920×1080): Max. 20 fps; 720P (1280×720): Max. 30 fps; |
Lentila | 2.8mm@F2.0, unghi vizualizare 98° |
Compresie | H.265+, H.265, H.264, MJPEG , Dual-stream |
Iluminare minima | Color: 0.01 Lux (F2.0, AGC ON), 0 Lux cu IR pornit |
Distanta IR | 30 metri, IR-CUT filter cu AUTO-switch |
Alimentare | 12 V DC ± 25% , PoE (802.3af) |
Consum | max. 6.5W |
Temperatura de operare | -30°C ~ +60°C, IP67 |
Dimensiuni | 177.6 mm × 66.2 mm × 67.8 mm |
Greutate | 270 gr. |
Interfata retea | RJ45 10/100Mbps |
Audio | Nu are |
Alarma | Nu are |
WDR | 120dB |
Inregistrare locala | Nu are |
NVR cu 4 canale IP, Ultra HD rezolutie 4K – 4 porturi POE – HIKVISION
Specificatii
Model / producator | HIKVISION |
Inregistrare | 8MP/5MP/3MP/1080P/720P/WD1 |
Nr Canale | 4-ch @ 8MP |
Redare | 1-4 canale sicronizate |
Iesire Video | HDMI 4K (3840 × 2160); VGA: 1920 × 1080 |
Stocare | 1 x HDD max 6TB |
Compresie | H.265/H.264/H.264+ |
Alarma | Nu are |
Alimentare | 48V DC, Consum: <10W (fara HDD si PoE) |
Dimensiuni | 315 × 240 × 48 mm |
Greutate | cca. 1 Kg (fara HDD) |
Capacitate decodare | 1-ch@8MP / 4-ch @ 1080P |
PoE | 4 porturi 10 /100 Mbps |
Latime banda | intrare 40Mbs / iesire 80Mbs |
Putere PoE | 50 W |
Interfete externe | 2xUSB, 1 x LAN 10/100/1000Mb |
Audio | 1 intrare / 1 iesire |
Cablu CAT6 FTP ecranat 0.5mm 24AWG CUPRU SOLID rola 100m
Cablu CAT6 FTP ecranat 0.5mm
- FTP CAT 6 HIGH QUALITY 99.99% CUPRU
- SOLID 4X2X0.5 mm ecranat cu folie de AL,
- Invelis exterior PE negru 0, 92 mm,
- Protectie la UV+PET+invelis dublu 2.6mm PVC,
- Rola 100 M
- Culoare negru
- ISO/IEC11801 EN50173, CE&RoHS PASS FLUKE TEST
HDD Toshiba DT01ACA 1TB
- Capacitate: 1 TB
- Viteza de rotatie: 7200 rpm
- Buffer: 32 MB
- Interfata: SATA 3
- Rata de transfer: SATA 600 MB/s
- Dimensiuni(W x D x H):101.6 x 147 x 26.1 mm
- Greutate: 450 g
