Camera IP Dahua WizMind 8MP Full-color Duo Splicing 180, lumina calda 40m, lentila 3.6mm, microfon si speaker, alarma 1 in/1 out, PoE+, IPC-PDW5849-A180-E2-ASTE

Camera IP Dahua IPC-PDW5849-A180-E2-ASTE este o camera de supraveghere panoramica din seria WizMind, cu doua senzori CMOS de 1/1.8″, rezolutie maxima 8MP si imagine wide-angle de 180. Modelul foloseste tehnologie Full-color, iluminare cu lumina calda pana la 40 m si lentila fixa de 3.6mm, fiind potrivit pentru monitorizarea zonelor largi precum parcari, curti, hale, spatii comerciale, perimetre sau zone de acces. Camera include microfon incorporat, speaker, audio bidirectional, alarma 1 in/1 out, stocare pe card microSD pana la 512GB si functii AI precum SMD 3.0, protectie perimetrala, heat map, people counting si smart object detection. Alimentarea se poate face la 12V DC, PoE+ sau ePoE, iar carcasa metalica cu protectie IP67 permite instalarea la exterior.

Specificatii tehnice:

• Tip produs: camera IP panoramica duo splicing
• Brand: Dahua
• Serie: WizMind 5 Series, Full-color
• Model: IPC-PDW5849-A180-E2-ASTE
• Senzor imagine: dual 1/1.8″ CMOS
• Rezolutie maxima: 4096 x 1800 pixeli, 8MP
• Imagine panoramica: 180 wide angle splicing
• ROM: 128MB
• RAM: 1GB
• Sistem de scanare: progresiv
• Viteza obturator electronic: auto / manual, 1/3 s – 1/100000 s
• Iluminare minima color: 0.0005 lux @ F1.0, 30 IRE
• Iluminare minima alb-negru: 0.0002 lux @ F1.0, 30 IRE
• Iluminare minima cu iluminator activ: 0 lux
• Raport semnal/zgomot: >56 dB
• Distanta iluminare lumina calda: pana la 40 m
• Control iluminator: automat
• Numar iluminatoare: 4 lumini calde
• Ajustare Pan: 0 – 360
• Ajustare Tilt: 4 – 90
• Ajustare rotatie: 0 – 360
• Tip lentila: fixa
• Montura lentila: M16
• Distanta focala: 3.6mm
• Diafragma maxima: F1.0
• Camp vizual orizontal: 180 ±10
• Camp vizual vertical: 48
• Control iris: fix
• Distanta minima de focalizare: 3.6 m
• DORI detectie: 70.3 m
• DORI observare: 28.1 m
• DORI recunoastere: 14.1 m
• DORI identificare: 7.0 m
• IVS protectie perimetrala: intrusion, tripwire, fast moving, loitering detection, people gathering, parking detection
• Clasificare IVS: persoane si vehicule
• Heat Map: da
• Smart Object Detection: obiect abandonat, obiect lipsa
• People Counting: intrari, iesiri, treceri, rapoarte anuale / lunare / zilnice
• Numarare persoane in zona: da, 4 reguli
• Queue Management: da, 4 reguli
• Compresie video: H.265, H.264, H.264H, H.264B, MJPEG pe sub-stream
• Smart Codec: Smart H.265+, Smart H.264+
• AI Coding: AI H.265, AI H.264
• Main stream WDR off: 4096 x 1800 la 1 – 25 fps
• Sub stream WDR off: 1024 x 452 la 1 – 25 fps
• Third stream WDR off: 1920 x 832 la 1 – 25 fps
• Main stream WDR on: 4096 x 1800 la 1 – 20 fps
• Sub stream WDR on: 1024 x 452 la 1 – 20 fps
• Third stream WDR on: 1920 x 832 la 1 – 20 fps
• Numar stream-uri: 3
• Rezolutii suportate: 8M 4096 x 1800, 6.5M 3840 x 1680, 4M 3840 x 1080, 4M 2880 x 1264, 1.6M 1920 x 832, 0.7M 1280 x 560, 0.5M 1024 x 452
• Control rata biti: CBR / VBR
• Rata biti H.264: 9 kbps – 8192 kbps
• Rata biti H.265: 9 kbps – 8192 kbps
• Zi / noapte: color / alb-negru
• BLC: da
• HLC: da
• WDR: 140 dB
• SSA: da
• Balans de alb: auto, natural, street lamp, outdoor, manual, regional custom
• Control gain: auto
• Reducere zgomot: 3D NR
• Detectie miscare: pornit / oprit, 4 zone rectangulare
• ROI: da, 4 zone
• Masca de confidentialitate: 4 zone
• Defog: da
• Microfon incorporat: da
• Speaker incorporat: da
• Audio bidirectional: da
• Intrare audio: 1 canal RCA
• Iesire audio: 1 canal RCA
• Compresie audio: G.711a, G.711Mu, PCM, G.726, G.723
• Evenimente alarma: fara card SD, card SD plin, eroare card SD, deconectare retea, conflict IP, acces ilegal, detectie miscare, sabotaj video, tripwire, intrusion, fast moving, obiect abandonat, obiect lipsa, loitering detection, people gathering, parking detection, schimbare scena, detectie audio, detectie tensiune, alarma externa, SMD, people counting in area, stay detection, people counting, exceptie securitate
• Port retea: RJ45 10/100 Base-T
• Protocoale retea: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, Bonjour
• Interoperabilitate: ONVIF Profile S / G / T, CGI, Milestone
• Utilizatori / host: 20
• Latime de banda totala: 80M
• Stocare: FTP, SFTP, NAS, card microSD pana la 512GB
• Browsere compatibile: IE 11 si versiuni ulterioare, Chrome, Firefox
• Software management: Smart PSS, DSS, DMSS
• Aplicatie mobila: iOS, Android
• Certificari: CE-LVD, CE-EMC, FCC, UL/CUL
• Intrare alarma: 1 canal, 5mA 3V – 5V DC
• Iesire alarma: 1 canal, 300mA 12V DC
• Alimentare: 12V DC ±30% / PoE+ 802.3at / ePoE
• Consum basic 12V DC: 4.8W
• Consum basic PoE: 5.5W
• Consum maxim 12V DC: 10.5W
• Consum maxim PoE: 11.8W
• Temperatura de functionare: -40C pana la +60C
• Umiditate de functionare: maximum 95%
• Temperatura de stocare: -40C pana la +60C
• Protectie la intemperii: IP67
• Material carcasa: metal
• Dimensiuni: 122 x 131.9 mm
• Greutate neta: 990 g
• Greutate bruta: 1150 g
